Single 10

Line Gemini

Handle Gemini-Decor

Code Colour Length Item Collective packaging
02284 Silver 2700mm 1pcs 10pcs
02283 Light brown 2700mm 1pcs 10pcs
02285 Gold 2700mm 1pcs 10pcs
03607 matt black 2700mm 1pcs 10pcs

Top track Single

Code Colour Length Item Collective packaging
01255 Silver 1700mm 1pcs 12pcs
01246 Light brown 1700mm 1pcs 12pcs
01256 Silver 2350mm 1pcs 12pcs
01247 Light brown 2350mm 1pcs 12pcs
01257 Silver 3000mm 1pcs 12pcs
01248 Light brown 3000mm 1pcs 12pcs
05989 matt black 3000mm 1pcs 12pcs
01507 Silver 6000mm 1pcs 12pcs
01508 Light brown 6000mm 1pcs 12pcs

Bottom track Hide G

Code Colour Length Item Collective packaging
01977 Silver 3000mm 1pcs 60pcs
01986 Light brown 3000mm 1pcs 60pcs

Bottom track Hide M

Code Colour Length Item Collective packaging
01978 Silver 1700mm 1pcs 60pcs
01990 Light brown 1700mm 1pcs 60pcs
01979 Silver 2350mm 1pcs 60pcs
01991 Light brown 2350mm 1pcs 60pcs
01980 Silver 3000mm 1pcs 60pcs
01992 Light brown 3000mm 1pcs 60pcs
02676 Silver 6000mm 1pcs 60pcs
02677 Light brown 6000mm 1pcs 60pcs

Bottom track Hide N

Code Colour Length Item Collective packaging
02579 Silver 1700mm 1pcs 24pcs
02576 Light brown 1700mm 1pcs 24pcs
02580 Silver 2350mm 1pcs 24pcs
02577 Light brown 2350mm 1pcs 24pcs
02581 Silver 3000mm 1pcs 24pcs
02578 Light brown 3000mm 1pcs 24pcs
05905 matt black 3000mm 1pcs 24pcs
02681 Silver 6000mm 1pcs 24pcs
02680 Light brown 6000mm 1pcs 24pcs

End cap for track Hide N

Code Colour Item Collective packaging
20208 Silver 1set 1set

H-Profile H10

Code Colour Length Item Collective packaging
00207 Silver 3000mm 1pcs 30pcs
00204 Light brown 3000mm 1pcs 30pcs
00208 Gold 3000mm 1pcs 30pcs
02493-Y Light brown with brushed effect 3000mm 1pcs 30pcs
03104 Cognac with brushed effect 3000mm 1pcs 30pcs
03103 Black with brushed effect 3000mm 1pcs 30pcs
05181 White matt 3000mm 1pcs 30pcs
04050 White gloss 3000mm 1pcs 30pcs
05303 matt black 3000mm 1pcs 30pcs
05182 Black gloss 3000mm 1pcs 30pcs
05971 Grafit lakier strukturalny 3000mm 1pcs 30pcs
06125 Czarny lakier strukturalny 3000mm 1pcs 30pcs

H-Profile H10 Decor

Code Colour Length Item Collective packaging
01617 Silver 3000mm 1pcs 30pcs
01616 Light brown 3000mm 1pcs 30pcs

H-Profile H30 Decor

Code Colour Length Item Collective packaging
00222 Silver 3000mm 1pcs 20pcs
00219 Light brown 3000mm 1pcs 20pcs
03212 White gloss 3000mm 1pcs 20pcs
03606 matt black 3000mm 1pcs 20pcs

H-Profile Mini H04/07

Code Colour Length Item Collective packaging
04210 Silver 3000mm 1pcs 60pcs
04209 Light brown 3000mm 1pcs 60pcs
05902 matt black 3000mm 1pcs 60pcs

Guiding carriage Gemini

Code Item Collective packaging
10204 1set 50set

Bottom carriage WD10V HI-TEC

Code Item Collective packaging
10238 1set 50set

Stopper for track Hide

Code Item Collective packaging
20212 1set

Textile seal (doorstop) inserted

Code Dimensions Length Item Collective packaging
20288-SV 14 x 4.0 50 m 1set 0.02set
20334-SV 14 x 4.0 50 m 1set 0.02set
20429-SV 14 x 4 200 m 200roll 200roll
20428-SV 14 x 4 200mb 200roll 200roll
20224-SV 14.5 x 4.0 50 m 1set 0.02set
20094-SV 14.5 x 4.0 200 m 200roll 200roll

Screw

Code Dimensions Item Collective packaging
20001 6.3 x 32.0 1pcs 2000pcs

End cap for track SINGLE with bottom and top stoppers

Code Colour Item Collective packaging
20179 Silver 1set 24set

Stopper HI-TEC

Code Item Collective packaging
20080 1pcs 100pcs

Wall bracket for track Single

Code Item Collective packaging
20213 1set 1set

Hinge for SEVROMATIC MINI TOP

Code Item Collective packaging
20265-SV 1set 200set

Positioning jig

Code Item Collective packaging
20016 1pcs
20173 1pcs 150pcs

Bottom track Hide W II

Lower horizontal profile Decor

Code Colour Length Item Collective packaging
00161 Silver 1700mm 1pcs 12pcs
00152 Light brown 1700mm 1pcs 12pcs
00152-A Light brown 1700mm 1pcs 12pcs
00164 Gold 1700mm 1pcs 12pcs
00162 Silver 2350mm 1pcs 12pcs
00153 Light brown 2350mm 1pcs 12pcs
00153-A Light brown 2350mm 1pcs 12pcs
00165 Gold 2350mm 1pcs 12pcs
00163 Silver 3000mm 1pcs 12pcs
00155 Light brown 3000mm 1pcs 12pcs
00166 Gold 3000mm 1pcs 12pcs

Track seat

Started Compositor 5
ApplicationSliding doors
TrackSingle
Carriage systemBottom
Top guideBall bearing carriage
Bottom guideBall bearing carriage (load bearing)
ConstructionFrame
Filling thickness10 mm
Filling type10 mm MFC or 4.5 mm safety glass or 4 mm mirror
Max. door load50 kg
Max. handle length2700 mm
Max. track length6000 mm
Textile door stopsYes
Anti-dust brushesn/a
Sales programmeComponents can be purchased separately
Decorative profile programmeDECOR

USAGE: built-in furniture, walk-in wardrobes, wardrobes, attics.
